• All-in-One ไม่ต้องต่อ PC / ไม่ต้องต่อ Signage Box / ไม่ต้องต่อ Android Box หรืออุปกรณ์ใดๆ ครบจบในจอ
  • ให้ภาพคมชัดด้วยจอแบบ IPS ที่ความละเอียดระดับ FHD
  • หน้าจอที่ให้ความสว่างสูงถึง 400nit
  • ตั้งเวลาเปิด/ปิด อัตโนมัติ
  • รองรับการทำงานต่อเนื่อง 24/7
Weight 5700 g
Dimensions 72.94 × 42.89 × 5.55 cm

3 Year


AUDIO OUT (x1), HDMI (x3), IR IN (x1), RJ45 IN LAN (x1), RS-232C IN (x1), RS-232C OUT (x1), USB (x1)

Screen Size



Screen Size 32″
Panel Technology IPS
Native Resolution 1,920 X 1,080 (FHD)
Brightness (Typ.) 400 nit
Contrast Ratio 1,100 : 1
Dynamic CR 1,000,000 : 1
Viewing Angle (H x V) 178 × 178
Response Time 10 ms (G to G)
Surface Treatment (Haze) 1.00%
Operation Hours (Hours / Days) 24/7
Orientation Portrait / Landscape
Mechanical Specification
Bezel Color Black
Bezel Width 13 mm (T/R/L), 18 mm (B)
Weight (Head) 5.7 kg
Weight (Head+Stand) 6.5 kg
Monitor Dimensions (W × H × D) 729.4 mm × 428.9 mm × 55.5 mm
Monitor Dimensions with Stand (W × H × D) 729.4 mm × 481 mm × 154.2 mm
VESA™ Standard Mount Interface 200 × 200 mm
Key Feature Internal Memory 8 GB, Built-in Wi-Fi, Temperature Sensor, Auto Brightness Sensor, Local Key Operation, webOS 6.0, Embedded CMS (Local Contents Scheduling, Group Manager), USB Plug & Play, Fail Over, Background Image (Booting Logo Image, No Signal Image), Screen Share, Play via URL, Setting Data Cloning, SNMP, ISM (Image Sticking Minimization) Method, Control Manager, Smart Energy Saving, PM Mode, Wake on LAN, Beacon, HDMI-CEC (Compatibility may differ by equipment), SI Sever Setting, webRTC, Pro:Idiom
Environment Conditions
Operation Temperature 0 °C to 40 °C
Operation Humidity 10 % to 80 %
Power Supply AC 100-240 V~, 50 / 60 Hz
Power Type Built-In Power
Power Consumption
Typ./Max. 55 W / 75 W
BTU (British Thermal Unit) 187.67 BTU/Hr (Typ.), 255.911 BTU/Hr (Max.)
Safety CB / NRTL
EMC FCC Class “A” / CE
ErP No
Software Compatibility
SuperSign CMS Yes
SuperSign Control / Control+ Yes
SuperSign WB Yes
SuperSign Media Editor Yes
LG ConnectedCare Yes
Promota Yes (Not available for Europe/CIS Region)
Input HDMI (3, HDCP 2.2), USB 2.0 ( Type A)
Output Audio Out (Off / Fixed / Variable)
External Control RS232C In (Phone-jack), RJ45 (LAN) In, IR In
Speaker Yes (10 W x 2 ea)
Basic Remote Controller, Power Cord, QSG, HDMI Cable, Phone to RS-232C Gender
Optional Stand (ST-322T), Wall Bracket (LSW230B), VESA Adapter (AM-B220S)

LG webOS Standard Signage

* All images in this web page are for illustrative purposes only and may differ from the actual product.

High-Performance with webOS 6.0

webOS 6.0, upgraded in SoC and web engine, is available on SM5J for a smooth execution of several tasks. LG webOS smart signage platform enhances user convenience with intuitive GUI and provides to SI or/and developers simple app development tools such as SDK (Software Development Kit), SCAP, sample applications.

Various Sensor Connection

LG webOS smart signage platform helps to easily provide additional solutions by supporting simple connections with external sensors* such as GPIO, NFC/RFID, temperature sensors, etc., via USB plug-in.

* External sensors need to be purchased separately and tested for compatibility with webOS platform.

Mobile & Web Monitoring

Through the Control Manager, the embedded web monitoring solution, you can control and monitor the status of the SM5J series displays in different locations in real-time. It is available on internet connected devices, allowing you to flexibly and rapidly respond to emergency situations.

* The mobile devices need be connected with the Signage IP address and can control one Signage at a time.
** Control Manager is optimized for Google Chrome 56 version and above.

Real-Time LG ConnectedCare Service

Maintenance is easy and fast with the optional LG ConnectedCare* service, a cloud service solution provided by LG. It remotely manages the status of displays in client workplaces for fault diagnosis and remote-control services, supporting the stable operation of clients’ businesses.

* The availability of the ‘LG ConnectedCare’ service differs by region, and it needs to be purchased separately.

LG’s Simple Advertisement Helper, Promota

Using LG’s Promota* application, downloadable on a mobile device, you can easily create your own display contents. With Promota, you can add text and images to create an online profile for your business as well as deliver information such as event news, seasonal menus, promotions, and even more while recommending easy-to-use templates relevant to your industry.

* LG Promota is can be downloaded from the App Store and Google Play store. (Not available for Europe/CIS Region)

Real-Time Promotion

With Beacon and Bluetooth® Low Energy (BLE), shop managers can provide coupons and information in real-time.

Content Sharing

Content Mirroring among devices is available on a Wi-Fi network.

Wireless Access Point

The SM5J series operates as a virtual router which can be an wireless access point for mobile devices.

ENERGY STAR® Certified
